{{0}}.4mm Male Board To Board Plug BB0.4M-1.0

Product AttributesSupply Ability Additional InformationPackaging Delivery<>

Overview

Product Attributes

Model No.: BB{{0}}.4M-1.0XXX02Brand: ANTENKInterface Type: Ac/DcHousing: PlasticPin: BrassPoles: OtherApplication: OtherCertification: OtherGender: MaleMaterial: BrassSupport Card Number: OtherOperating Frequency: High FrequencyClassification: Otherplace of origin: China

Supply Ability Additional Information

Packaging: bag packing,Tube packing, reel packingProductivity: 2000K/monthTransportation: Ocean,Air,ExpressPlace of Origin: ChinaSupply Ability: 2000K/monthCertificate: ISO9001HS Code: 8536909000Payment Type: T/T,Paypal,Western UnionIncoterm: FOB,CIF,EXW,FCA

Packaging Delivery

Selling Units:

Piece/Pieces

Package Type:

bag packing,Tube packing, reel packing

0.4mm Board to Board male connector mating Height=1.00mm

Specifications:

1.Materlal:

1-1.Molded portion:LCP resin(ul94-0).

1-2.Contact and post:copper alloy.

2.Surface treatment:

2-1.Terminal portion;base;Ni plating surface;

Au plating(except the terminal tips);exposed nickel portions.

2-2.Metal Clips:base;Ni plating surface;Au flash plating

(except the terminal tips)or base;Ni plating surface;

Sn flash plating (except the terminal tips)

3.Characteristics:

3-1.Rated voltage:60V AC/DC

3-2.Rated curren:0.3A/contact(Max.5A at total contact)

3.3.Insulation resistance:Min.1000MΩ(initial)

3.4.Breakdown voltage:150V AC fou 1 min.

3-5.Saltwater spray resistance(header and socket mated:24 hours,

insulact resistance max.90mΩ.

3-6Contact resistance:Max.90mΩ.

3-7.Ambient temperature:-55 degree plus 85 degree .

3-8.Storage temperature:-55 degree plus 88 degree (product only);

-40 degree plus 50 degree (emboss packing).

3-9.Composite insertion force:Max.0.918N/contacts X contacts(initial).

3-10.Composite removal force:Min.0.165N/contacts X contacts.

3-11.Post holding force:Min.0.49N/contacts.

3-12.Insertion and removal life:50times.

FAQ

1, Can we get some samples? Any charges?

Yes, free existing labels, you need to pay shipping cost.

 2. How can we get a quote?

Contact us with specification: such as material, design, size, shape, color, quantity,  surface finishing, etc.

 3. Can you help with the design?Yes, Simply design free, special design need to pay.                                                                             4. What's the trade term and payment term?Amount less than 1000, 100 percent  paid before production, more than 1000 can be negotiated!

T/T, Western Union, PAYPAL etc.

5.  May I have new sample made with my design for confirmation?

Yes. Sample charge means set up charge for production line, little quantity  we suggest that straight for production. Large quantity we suggest that sample   first, and sample fee can be refund.

QUALITY CONTROL

We have QC person stay on the production lines do to the inspection.All products must have been inspected before delivery.we do inline inspection and final inspection.

1.All raw material checked once it arrive our factory.

2.All pieces and logo and all details checked during production.

3.All packing details checked during production.

4.All production quality and packing checked on final inspection after finished.

Q: Are you trading company or manufacturer? A: We are professional manufacturer specialized in orthopedic and sport products. And we trade our products with our clients directly.

Q: Can you do OEM and ODM?

A: Yes, OEM and ODM are both acceptable. The material, color, style can customize, the basic quantity we will advise after we discuss.

Q: Can we use our own logo?

A: Yes, we can print your private logo according to your request.

Q: How many packaging do you have?

A: We have five packages including PE bag, hand bag, zip lock bag, colorful box and

BB{{0}}.4M-1.0XXX02
